Manufacturer for 3 Knife Book Trimmer - QS100Z Automatic Three Knife Trimmer (Intelligent Model) – Eureka

1. The main machine adopts servo drive system, which can accurately match the operation precision of other parts of the machine and the protection setting of torsion force, greatly improving the cutting precision and service life of the machine.

2. The book delivery trolley adopts high-precision double lanes, which greatly improves the service life and accuracy. The book delivery trolley adopts servo system to complete transmission, which can automatically adjust front knife in the touch screen, and that is convenient, accurate and durable.

3. The moving part of book clamp trolley adopts high-precision lane, which is precise and durable. And clamp force is controlled by Festo cylinder and program.

4. The side knife is cooperatively controlled by motor, encoder and ball screw, which is adjusted automatically in touch screen setting interface. And it’s equipped with auto-loose/ auto-lock side knife function (patent).

5. Puzzle adopts drawer type, its bottom equipped with linear guide rail so that its replacement for different specification is very convenient and it also equipped with auto-induction recognition system, that could avoid wrong specification risk between puzzle and cutting due to auto adjustment of specification. The touch screen gives out error message warning and lock machine for protection when it has setting error.

6. Pressure of book pressing plate is adjusted automatically in touch screen.

7. The mechanical arm for place book in order is controlled by high-precision lane and servo system, which is automatically adjusted in touch screen. The adjustment is convenient, precise and durable.

8. The book pressing device adopts up-pressing device, which is durable, stable and compressed spring is not easy to damage. (Patent)

9. The touch screen can fully adjust the specifications and dimensions of the front knife, side knife and mechanical arm. And the order memory function, order can be saved or deleted freely, also can be free to set the number and note the name, so that the next time to do the same order can be efficiently called out。

10. Equipped with front knife fast installation device and side knife fast installation device.

11. Equipped with book spine protection device, which prevents spine from crack. (Side knife cutting range: ≥150mm).

12. Front knife waste paper edge blowing device. Side knife waste paper edge blowing device.

13. Equipped with book lateral feeding jogging device.

14. Equipped with blade silicone oil injection device (Prevent hot melt glue from sticking on blade).

15. Equipped with book delivery trolley blowing device (Turn on this function when using thin cover or cover upwarps in high speed)

16. The machine is equipped with air supply pressure detection system. when the air pressure can’t reach its air supply pressure, the touch screen will have warning and stop machine for protection.

17. The electrical cabinet is equipped with thermal conversion cooling system, which can greatly reduce the failure rate of electrical appliances.

18. The finished product outputs by book delivery device and book delivery is in order and stable.

19. The whole machine is equipped with automatic oil supply system.

20. The whole machine is equipped with oil receiving pan to avoid the occurrence of oil dripping and leaking out of the ground.

21. Each door is equipped with a protection switch, the machine automatically stops running when the door is opened.

1、The casting adopts HT200, the main stressed casting part adopts QT600.

2、The electric control system adopts DELTA brand.

3、The auxiliary electric device adopts CHINT brand.

4、Servo system adopts HECHUAN brand.

5、Reducing mechanism adopts ZHONGDA brand.

6、Photoelectric and proximity switch adopt OMRON brand.

7、Linear guide rail and ball screw adopt TSC brand.

8、Synchronous belt adopts Italy MEGADYNE brand.

9、Fastening piece adopts PENCHI brand.

10、Bearing adopts HARBIN brand.

The company is equipped with a Taiwan industry and trade Longmen processing center, a Wannan Longmen processing center. Other model processing center has ten. QS100Z automatic three knife trimmer can be ensured the accuracy of parts and parts of the mutual matching. Improve the cutting precision of the machine.
