Single Pass digital Printer
| Application | Corrugated cartons, paper boxes/bags, pizza boxes, rolls.etc. | |||||
| Colors | C/M/Y/K | |||||
| Ink | Dye & Pigment | |||||
| Printhead | HP Printhead | |||||
| Printer model | EDP215 | EDP430 | EDP645 | EDP860 | EDP1075 | EDP1290 |
| Print head quantity | 1 PCS | 2PCS | 3PCS | 4PCS | 5PCS | 6PCS |
| Printing width | 215MM | 430MM | 645MM | 860MM | 1075MM | 1290MM |
| Max material width | 680MM | 1200MM | 1600MM | 20000MM | 2500MM | 2500MM |
| Print height | 15CM | 8CM | 8CM | 8CM | 8CM | 8CM |
| Print speed | 30m/min | |||||
| Resolution | 1200×1346dpi | |||||
1.Muti-task continuous printing, no indirect automatic switching of printing pictures.
2.30m/min printing speed, save more time.
3.Using HP printheads, 1 to 6 printheads are optional, long life, low price and low maintenance cost.
4.Supports roll-to-roll printing, there is no limit to the length of the roll.
5.The ink circulation system allows the entire ink circuit system to circulate smoothly, taking away the air in the ink tube to ensure normal ink supply without affecting the printing accuracy.
6.Pigment ink and dry ink can be used.
7.High-definition touch screen, PLC operating system, simple operation, custom programming.
8.The combination design of pressing wheel and pressing sheet ensures that the material passes under the print head smoothly and stably to prevent damage to the print head.
9.Conveyor belt punching design reduces friction with the printing platform and effectively dissipates heat. With suction, the printing material is firmly adsorbed.
10.19 years of printer factory, completely independent research and development, in the same quality, price, printing size, there is no competitor.
